About R&G Machine Services
Expert Calibration and Service for Optical Comparators
R&G Machine Services specializes in the calibration, maintenance, and repair of optical comparators used in quality control and precision measurement. Our team ensures your equipment operates at peak accuracy, supporting manufacturing excellence and compliance with industry standards.
Remanufactured and Certified Used Optical Comparators
Starrett HD400
$14,500
Serial NO. 10286-L
16" x 6" (400mm x 150mm) X-Y travel workstage
All metal construction with hard-anodized stage tooling plate
16" (400mm) diameter screen
Dual-lens mounting system with 10X and 20X lenses
Collimating condenser with yellow/green filter and provision to mount further
accessories
Linear encoder (glass scale) with 20μin (0.5μm) resolution on both X and Y axes
LED profile and surface illumination
Fully retractable flexible duplex fiber optic surface illumination
Digital protractor for accurate
Starrett HD400
$14,500
Serial NO. 10286-K
16" x 6" (400mm x 150mm) X-Y travel workstage
All metal construction with hard-anodized stage tooling plate
16" (400mm) diameter screen
Dual-lens mounting system with 10X and 20X lenses
Collimating condenser with yellow/green filter and provision to mount further
accessories
Linear encoder (glass scale) with 20μin (0.5μm) resolution on both X and Y axes
LED profile and surface illumination
Fully retractable flexible duplex fiber optic surface illumination
Digital protractor for accurate
Starrett HE400
$8,000
Serial NO. 8721F
10" x 4" (250mm x 100mm) X-Y travel workstage
All metal construction with hard-anodized stage tooling plate
16" (400mm) diameter screen
Single-lens mounting system with 10X lens
Collimating condenser with yellow/green filter and provision to mount further
accessories
Linear encoder (glass scale) with 20μin (0.5μm) resolution on both X and Y axes
Halogen profile and surface illumination
Fully retractable flexible duplex fiber optic surface illumination
Digital protractor for accurate angle
Starrett HE350
$4,800
8" x 4" X-Y travel workstage
All metal construction with hard-anodized stage tooling plate
14" (400mm) diameter screen
Single-lens mounting system with 31.25X lens
Collimating condenser with yellow/green filter and provision to mount further
accessories
Linear encoder (glass scale) with 20μin (0.5μm) resolution on both X and Y axes
Halogen profile and surface illumination
Fully retractable flexible duplex fiber optic surface illumination
Digital protractor for accurate angle measurements (1' resolution)
J&L PC14-A
TBD
Serial NO. E37711
Remanufactured with 0.001mm scales and Metlogix MX200 Geometric DRO
heavy duty 30" x 6" work stage with 8" of horizontal X-axis travel
4" motorized Y axis vertical travel, constant speed with manual fine adjust
Long Life LED profile projection
Options built to order
